Product introduction
The Aierway GGJ Low-Voltage Reactive Power Compensation Cabinet is a specialized, intelligent power quality solution designed to improve energy efficiency, stabilize voltage levels, and reduce power losses in low-voltage electrical systems. By dynamically compensating for reactive power, it optimizes the power factor of the grid, helping industrial, commercial, and utility users comply with energy regulations, lower electricity costs, and enhance overall system performance.
Key Features
1. Dynamic & Automatic Compensation
– Employs fast-switching thyristor or contactor-based capacitor banks to provide real-time reactive power compensation.
– Equipped with an intelligent controller that continuously monitors the power factor, voltage, and current, automatically switching capacitor stages in/out to maintain a target power factor (typically ≥0.95).
2. Modular & Scalable Design
– Standardized modular capacitor banks allow flexible capacity configuration and easy expansion based on load requirements.
– Multiple compensation stages (e.g., 6, 8, 10, or 12 steps) enable fine-tuned adjustment to varying reactive power demands.
3. Advanced Protection & Safety
– Comprehensive protection features include overcurrent, overvoltage, undervoltage, overtemperature, and harmonic suppression.
– Optional detuned reactors (e.g., 5.67%, 7%, 14%) are available to prevent resonance and mitigate harmonic distortion.
Outline and dimensions of installation
